22 dangerous cuts: a selection of weapons from an unusual angle (22 photos)

Yesterday, 10:00
0
Category: weapon, 0+

What have you seen in cross-section - tools, books, cars. But today we have unusual cuts - exclusively for military purposes. This is also very interesting - to look into the “soul” of objects that bring death and protection at the same time.





Sectional fragmentation grenade



Yugoslav fragmentation hand grenade M75





Some type of grenades







Anti-tank mine PRB-ATK-M3A1



High explosive mine



M2 (60mm mortar): USA



Cumulative 125 mm rounds ZVBK 16 and ZVBK 25.



Ainet remote detonation system. The T-80UK and T-90 tanks are equipped with the Ainet system, which ensures the detonation of the OFS at a given point in the trajectory







Ammo







The design of German armor-piercing shells. Two on the left for Kwk 36 and FLAK 1836 - a Panzergranate projectile with a bottom fuse and a conical case with a heating element inside and a PZGR 39, with a smaller number of explosives without a case. On the right for KWK 43, PAK 43 and FLAK 41.



120 mm M829A4 finned sabot projectiles (BOPS) for Abrams



Leopard in section



Section of a 120 mm BOPS for a tank gun.



Revolver



Section of the turret of the dreadnought "Viribus Unitis"
